Melt flow rate testing instrument XNR-400B

Melt flow rate testing instrument » XNR-400B

Pictures available of Melt flow rate testing instrument:

XNR-400B

Melt flow rate testing instrument

Model: XNR-400B

Enquiry Now

Melt flow rate testing instrument Details

Instrument overview:


The machine not only suitable for high melting temperature PE, Nylon etc engineering plastics, but also suitable for PE, PS, ABS etc low melting temperature plastic testing. And it special suitable for university, R&D institution, quality inspection organization, plastic production enterprise, plastic products and petrochemical industry using.




Parameters and configuration:



熔体流动速率仪XNR-400B
Melt flow rate testing instrument XNR-400B
控温范围
Temperature control range
120℃~450℃,升温速度快、超调量极小
120℃~450℃, fast increase of temperature and low overshoot
温度显示示值误差
Temperature display indication error
≤±0.2℃,恒温精度高
≤±0.2℃, high constant temperature precision
温度显示分辨率
Temperature display resolution
0.1℃
恢复时间
Recover time
≤4min,在填料之后能迅速恢复恒温状态
≤4min, after fill material, it can recover the constant temperature state very fast
显示方式
Display type
彩色触摸屏幕显示、操作
Color touch screen display and operation
测量方法
Measuring method
质量法
Mass method
计时精度
Timing precision
0.1秒
0.1 second
切料方式
Blanking type
手动、自动两种种切料方式
Manual and automatic two blanking types
切样时间间隔
Cut time interval
1—36000S
口模材质
Bush material
碳化钨
Tungsten carbide
口模直径
Bush diameter
2.095±0.005 mm
仪器尺寸
Dimension
长260mm×宽400mm×高600mm
Length*width*height: 260x400x600 mm
所需空间
Space needed
前后0.4m, 左右0.4m
Front and back 0.4m, left and right 0.4m
